| 0719-0010 |
Double Acting, Retractable Pistons |
H20DERC | 1/2 | 5 | 3.75 | 0.625 | -- | -- | -- |
|
| 0719-0011 |
Double Acting, Retractable Pistons, EPR Seals |
H20DERCG | 1/2 | 5 | 3.75 | 0.625 | -- | -- | -- |
|
| 0720-0010 |
Double Acting |
H20DAC | 5/32 | 4.5 | 3.41 | 0.281 | -- | -- | -- |
|
| 0720-0011 |
Double Acting, EPR Seals |
H20DACG | 5/32 | 4.5 | 3.41 | 0.281 | -- | -- | -- |
|
| 0721-0010 |
Double Acting |
H20DBC | 1/4 | 4.5 | 3.5 | 0.375 | -- | -- | -- |
|
| 0721-0011 |
Double Acting, EPR Seals |
H20DBCG | 1/4 | 4.5 | 3.5 | 0.375 | -- | -- | -- |
|
| 0722-0010 |
Single Acting |
H20SBC | 1/4 | -- | -- | -- | 3.75 | 3.03 | 0.094 |
|
| 0722-0011 |
Single Acting, Floating Bracket |
H20SBFC | 1/4 | -- | -- | -- | 4.5 | 3.03 | 0.094 |
|
| 0722-0013 |
Single Acting, EPR Seals |
H20SBCG | 1/4 | -- | -- | -- | 3.75 | 3.03 | 0.094 |
|
| 0722-0014 |
Single Acting, Floating Bracket, EPR Seals |
H20SBFCG | 1/4 | -- | -- | -- | 4.5 | 3.03 | 0.094 |
|
| 0724-0010 |
Single Acting |
H20SAC | 5/32 | -- | -- | -- | 3.75 | 2.94 | -- |
|
| 0724-0011 |
Single Acting, Floating Bracket |
H20SAFC | 5/32 | -- | -- | -- | 4.5 | 2.94 | -- |
|
| 0724-0012 |
Single Acting, EPR Seals |
H20SACG | 5/32 | -- | -- | -- | 3.75 | 2.94 | -- |
|
| 0724-0013 |
Single Acting, Floating Bracket, EPR Seals |
H20SAFCG | 5/32 | -- | -- | -- | 4.5 | 2.94 | -- |
|
| 0724-0014 |
Single Acting |
H20SLC | 3/8 | -- | -- | -- | 4 | 3.16 | 0.219 |
|
| 0724-0016 |
Single Acting, EPR Seals |
H20SLCG | 3/8 | -- | -- | -- | 4 | 3.16 | 0.219 |
|
| 0725-0010 |
Double Acting |
H20DEC | 1/2 | 5 | 3.75 | 0.625 | -- | -- | -- |
|
| 0725-0011 |
Double Acting, EPR Seals |
H20DECG | 1/2 | 5 | 3.75 | 0.625 | -- | -- | -- |
|
| 0728-0010 |
Double Acting, Retractable Pistons |
H20DARC | 5/32 | 4.5 | 3.41 | 0.281 | -- | -- | -- |
|
| 0728-0011 |
Dbl Acting, Retr Pist, EPR Seals |
H20DARCG | 5/32 | 4.5 | 3.41 | 0.281 | -- | -- | -- |
|
| 0729-0008 |
Double Acting, Retractable Pistons |
H20DLRC | 3/8 | 4.5 | 3.62 | 0.5 | -- | -- | -- |
|
| 0729-0010 |
Double Acting, Retractable Pistons |
H20DBRC | 1/4 | 4.5 | 3.5 | 0.375 | -- | -- | -- |
|
| 0729-0011 |
Double Acting, Retractable Pistons, EPR Seals |
H20DBRCG | 1/4 | 4.5 | 3.5 | 0.375 | -- | -- | -- |
|
